Tech Parameters:

1 10.4’ high resolution color LED backlight display, with high contrast and wide viewing angle;

2 Adopt ARM7 embedded control system +FPGA signal processing system + well selected ultrasound hardware system, all make the unit more stable.

3 Menu operation system, with different languages according to requirement including Spanish, English, French, Russian and Portuguese;

4 Two probe sockets, auto-identify different optional probe;

5 Body marks:total 64 kinds body marks indicating probe position;

6 Display mode:B,2B,4B ,B/M,M ;

7 Adjustable depth: 10 grades, max depth to 236mm;

8 Gain:0~127dB;

9 Contrast:27~90dB;

10 Gray scale:256;

11 8 steps intelligent TGC;

12 Frame frequency: 30 frames /second

13 8 kinds pseudo colors;

14 Image storage: 4G hard disk to permanently store about 5000 frames images;without loss when power off.

15 Cine loop:256 frames;

16 Puncture guide function with 2 correctable puncture guiding lines(adjustable angle & position);

17 the gravel software package with real-time position line measurement

18 Normal measurement: distance,perimeter, area, volume, angle, length and area stenosis ratio measurement.

19 Cardio measurement:Depth, slope, heart rate, cycle;

20 Gynecology measurement and analysis: gynecology general measurement and gynecology report.

21 OB measurement including: 15 kind of obstetric software, several GA measurement, amniotic fluid index ,fetal growth curve and OB report.

22 Urology measurement and analysis: residual urine volume, prostate volume, and urology report .

23 One-key store: concise and practical;

24 One-key review:fast, practical image review function;

25 One-key Print;

26 One-key Transfer the current frozen image to net workstation to complete its image text report and print directly;

27 Concise and practical, easy operation. The system includes network workstation to complete data & report management (You don’t need to invest more to buy extra ultrasound working station);

28 Unique One-key-light keyboard function for black room use;

29 Display brightness adjustable;

30 Dual TV output: PAL/NTSC, can connect video printer when necessary;

31 Power supply:100-240V~ 1.2-0.6A frequency:50-60Hz;

32 Power supply adaptor output:DC12.8V 3.0A;

33 Main unit weight:4.5kg(without accessories)

34 Main unit dimension:256×150×326mm(L×W×H)
